Pearl Mini User Guide Connectivity status results
Connectivity status results
The following table describes the Connectivity status diagnostics results shown on the touch screen and the
Admin panel.
Table 74 Connectivity status diagnostics results
Diagnostic Description
Ethernet cable
Check if an Ethernet cable is detected and connected to the
LAN.
802.1x
Report the status of 802.1x negotiation and if the feature is
disabled on Pearl Mini. Status results include: disabled,
authenticated, in progress, and failed.
DNS
Check if Pearl Mini can resolve host names with their
associated IP address using the DNS server that is
configured for Pearl Mini. For information about setting a
DNS server IP address for Pearl Mini, see
Configure a static
IP address .
Captive portal
Check for connectivity issues caused by a Captive portal.
An okay result can indicate several conditions:
l No captive portal is detected and Pearl Mini can
successfully reach the Internet.
l A captive portal is detected and Pearl Mini can
successfully reach the public Internet.
Internet
Check if Pearl Mini is connected to the Internet by sending a
ping to IP address 8.8.8.8 on the Internet.
HTTP (port 80)
Check if traffic can be sent and received over the network
using HTTP port 80.
HTTPS (port 443)
Check if traffic can be sent and received over the network
using HTTPS port 443.
Support server
Check if the connection to the Epiphan support server is
enabled and if enabled, confirm that Pearl Mini can
establish communication with the server. A successful
connection is required to use the Epiphan Edge remote
login feature.
Epiphan Edge™
Check if the Epiphan Edge remote management feature is
disabled on Pearl Mini and if Pearl Mini can successfully
connect to Epiphan Edge.
Public IP Display the public IP address of this Pearl Mini. Knowing
