Pearl Mini User Guide Video output port resolution
Numberof
Displays
Cable 1 Cable 2 Output resolution
1
passive
converter
n/a
Any (1024Ч768, 1280Ч720, 1280Ч960, 1360Ч768,
1400Ч1050, 1920Ч1080)
1 n/a
Any (1024Ч768, 1280Ч720, 1280Ч960, 1360Ч768,
1400Ч1050, 1920Ч1080)
2
passive
converter passive
converter
2
active
converter or
DisplayPort
cable active
converter or
DisplayPort
cable
Displays can be set independently to any resolution up to
1080p (1024Ч768, 1280Ч720, 1280Ч960, 1360Ч768,
1400Ч1050, 1920Ч1080)
2
active
converter or
DisplayPort
cable
passive
converter
One of the two displays will fail to receive a signal.Do not
mix passive converters with active converters and
DisplayPort cables.
2
passive
converter
active
converter or
DisplayPort
cable
Related links
Set up the video output port using the Admin panel
Set up and enable MultiViewer
Select the video output source using the device screen
Monitor and select the video output source using Epiphan Live
Video output port resolution
The video output port's resolution (also known as frame size or display mode) defines the number of pixels
displayed horizontally and vertically. For example, the resolution 1920×1080 (1080p) produces an image that is
1920 pixels wide by 1080 pixels tall.
Pearl devices always assume that the output display uses square pixels.
The aspect ratio (eg. 4:3 or 16:9) describes the proportional relationship between the video output's pixel width
and height. The resolution 1920×1080 (1080p), for example, is quite a bit wider than it is tall. The ratio of its width
to height is 16 to 9, which has an aspect ratio that is 16:9.
