Pearl Mini User Guide Pearl Mini tech specs
Connectors
(2) HDMI type A (female)
(1) BNC (female)
(2) USB-A (female) - rear panel
(1) RJ-45 (female)
Aspect ratios 3:2, 4:3, 16:9, 16:10, and custom aspect ratios
Standard resolutions PAL, PAL wide, NTSC, NTSC wide
Resolution range 640×480 to 1920×1200
Frame rate Up to 60 fps
Input color spaces
HDMI: RGB 4:4:4, YC
R
C
B
4:2:2, YC
R
C
B
4:4:4
SDI: RGB 4:4:4, YC
R
C
B
4:2:2
Interlacing Yes
Maximum cable length for 3G
SDI
300 ft
Maximum cable length for
USB 3.0
6 ft
Audio inputs
Analog audio inputs
(2) XLR mic level/pro line level (+4.0 dBu) up to
12.3 V
RMS
, +24 dBu (balanced/unbalanced,
mono or L/R stereo pair) - Phantom optional
(2) 1/4" TRS pro line level (+4.0 dBu) up to to 12.3
V
RMS
, +24 dBu (balanced/unbalanced, mono or
two L/R stereo pairs)
(1) RCA consumer line level - 10 dBV (L/R stereo
pair)
(1) 3.5 mm stereo input for electret microphones
(unbalanced)
Connectors
(2) XLR/TRS combo jacks (female)
(2) RCA (female)
(1) 3.5 mm (female) - rear panel
Digital audio inputs 4
(1) SDI 5
(2) HDMI
(2) USB (rear panel)
(1) RTSP (embedded over Ethernet)
(1) SRT (embedded over Ethernet)
BETA DRAFT - 23
