2. Panel Operation
2 – 65 Operating Instructions – Rev. 1 / 7.2002
flat The flat button serves to select a flat (plain) matte.
wash The wash button serves to select a matte that is composed of a color wash bet-
ween matte 1 and matte 2.
If only the wash button lights up, it is possible to change the color wash individually
with the Softness, Position, and Angle controls.
Press Matte 1 or Matte 2 if you wish to adjust the matte with the Hue, Chroma, and
Luminance controls.
Adjusting the wash characteristics
Softness – Position – Angle
The Softness control permits adjusting the steepness, i.e. the width of the transi-
tion between the two colors. The Position control serves to shift the position of the
transition. With the Angle control, the transition angle can be rotated.
The Wiper/Text button is used to modulate the color wash between matte 1 and
matte 2 with the wipe or key signal selected for Matte Store.
For further information on the store control please refer to the section Video Store
Menu.
The Wiper/Text button is used to control the color wash in the wipe border to the
effect
that a complete washing between the colors is made in the border. The softness
of the transition can be adjusted with the Softness control. The border may be ad-
justed with the associated controls in the Wipe panel.
For further information on the wipe control please refer to the section Wipe Boder
Matte Menu.
Copying mattes
Adjusted mattes may be easily copied or replaced.
For further information please refer to the section Key Mattes Menu.
Hue/
Chroma/
Luminance/
Softness
Position
Angle
Wiper/Text
only with Col 1
Wiper/Text
with wipe border
