2. Panel Operation
2 – 6 Operating Instructions – Rev. 1 / 7.2002
Asynchronous Sources
Asynchronous (non-synchronous) sources are indicated by either a red or green-
flashing On Air depending on the on air status.
Note: Asynchronous picture signals are instantaneously switched through
by the switcher.
The yellow Uncal indicator lights when a change from the default settings on the
switcher has been made, such as, one or more of the following:
D
the bus correction is non-default
D
the selected source has a non-default input correction
Button delegates the Key bus buttons of the P/P panel to the following functions:
2nd
MaKE
ME2 ME3 ME1
Aux
Rec Ins-P Del
Macro or Aux Selection
...
Example: Part of the PGM / PST panel (RPS35–4/32)
3rd 4th MaKE
Selected
D
For special applications the Aux bus input button row can be moved from the
Aux Panel to the P/P panel.
D
Make Memo
t
function for storing and recalling macros. Operation with the
panel buttons see below. For operation with menu refer to section Config
Panel menu.
Uncal
MaKE/Aux
(only in P/P)
