Grass Valley XtenDD v.4.2.4 User Manual
Page 219
3. Menu Operation
3 – 72
Operating Instructions – Rev. 1 / 7.2002
The wipe icon list box displays all available wipe patterns. They are arranged in four
pages à thirty patterns (1st, 2nd, ROT, USER).
The listbox is used to pre-select the active main and the combine (in preparation)
pattern. The patterns can be scrolled up and down pagewise by a scrollbar. The
user can pre-select an item via mouse-click or digipot.
There are two cursors:
D
a blue one to select the main pattern
D
a black one to select the combine pattern. When both cursors rest on the same
icon a deep sky blue cursor is displayed. If one of these cursors is moved out
of the current page the previous/next is shown. Moving a momentarily not dis-
played cursor sets the listbox focus to that cursor’s page.
In the footer of the listbox the pattern types of both main and combine pattern are
shown:
The types are displayed as one of the following characters:
Clock
non-combinable
s
Matrix
J
Rectangle
F
Circle
Note:
Wipe Combine is in peparation!
3.8.1.1
Dialog Buttons
Selecting Adjust menu.
Selecting Border Matte menu.
Selecting Pattern List menu.
Return to the previous menu. For details refer to section Introduction.
Wipe Icon
Listbox
Adjust
Border Matte
Pattern List
Previous Menu
