Gasboy Fuel Point PLUS Station - Manual (Page 71)

Fuel Point PLUS Station Equipment Manual 71
Figure 6-26 - Software Upload Screen
1. In the File Type drop-down, select the type of software component
2. Click on the Browse button on the bottom screen. A file selection dialog appears
3. (Optional) In the Force Upload drop-down, change default to YES to enforce uploading a version
older than the current version installed in the system.
Note: use this option only when a previous software version must be installed.
4. Select the file and click Upload . The file is uploaded to the Wireless Gateway
5. Define how the execute the update. Select one of the following:
Update Immediate : The update is executed immediately after the component was
received by the Wireless Gateway
Update at Date & Time : The update is executed at a specific time. When this option
is selected, Update Time fields are displayed. Enter the update Date and Time
Update without Reset : Update is executed immediately, but new version takes effect
after the network is manually reset. See Saving Setup
Update at Admin Command (Manual) : The update is executed only after reset is
manually initiated by the user. See Saving Setup
Best Practice: It is highly recommended to update all units remotely via Master Wireless
Gateway to ensure all units are synchronized with the same software versions. See
Updating Software .
