Figure 9-2 - detaching the back cover, Figure 9-3 - pulling out the µwnr assembly, Figure 9-4 - replacing batteries – Gasboy Fuel Point PLUS Station User Manual
Page 103: Figure 9-2
Fuel Point PLUS Station Equipment Manual
103
Figure 9-2 - Detaching the Back Cover
2.
Pull out the µWNR assembly carefully, to avoid damaging the wires (see
Figure 9-3 - Pulling out the µWNR Assembly
3.
Release the two Phillips screws and take off the lid
4.
Slide the batteries out
5.
Slide a new set in, following the polarity signs on the battery compartment (see
Figure 9-4 - Replacing Batteries
