Gasboy Fuel Point PLUS Station - Manual (Page 6)

VI Fuel Point PLUS Station Equipment Manual
2.3.3.1. Wireless Gateway In-Pump Specifications 31
Chapter 3 WNR Description 33
3.1. General 33
3.2. Types of µWNR 33
3.3. Using the µWNR 33
3.4. µWNR Specifications 33
Chapter 4 Designing the Network Layout 35
4.1. General 35
4.2. Site Survey 35
4.3. Wireless Gateway Positioning 35
4.4. Location Recommendations 36
4.5. Maximum Distance 37
4.6. Network Design Scenarios 38
4.6.1. Scenario #1 - 1 Master Wireless Gateway Outdoor 38
4.6.2. Scenario #2 - 1 Master Wireless Gateway Outdoor + 1 Wireless Gateway Out-
door
38
4.6.3. Scenario #3 - 1 Master Wireless Gateway Outdoor + 1 Wireless Gateway Out-
door per Island
39
4.6.4. Scenario #4 - 1 Master Wireless Gateway Outdoor + 2 Wireless Gateway In-
Pump per Island
39
Chapter 5 Installing the Wireless Gateway 41
5.1. General 41
5.2. Installation Options 41
5.3. Approved Location 42
