Altera 40-Gbps Ethernet MAC and PHY MegaCore Function User Manual
Page 129
Address
Name
Applicable
Device(s)
Bit
Description
HW Reset
Value
Access
0x007
GX_CTRL1
Stratix IV
[31]
When set, places the
transceiver in Internal
serial loopback, from TX
to RX.
1’b0
RW
[30]
When asserted, the
transceiver channel’s
analog settings are read
on the rising edge of
clk_
status
.
1’b0
RW
[29]
When asserted, the
transceiver channel’s
analog settings are
written on rising edge of
clk_status
.
1’b0
RW
[28:4]
Specifies the analog
settings to write. Refer to
the following table for the
register fields which are
read on
GX_
REPLY[
24:0]
. Bits[28:4]
of this register
correspond to bits[24:0]
of the
GX_REPLY
register.
0x000000
RW
[3:0]
Specifies the logical
channel to select [0–9].
0x0
RW
0x008
GX_CTRL2
Arria V GZ,
Stratix IV, and
Stratix V
[1]
Specifies bit error inject
position 1 on rising edge.
1’b0
RW
[0]
Specifies bit error inject
position 0 on rising edge.
1’b0
RW
0x009
—
Arria V GZ and
Stratix V
–
Reserved.
—
—
0x009
GX_REPLY
Stratix IV
[26]
Reserved.
0
R
[25]
When asserted, indicates
that read data is valid.
1’b0
R
[24:0]
Contains the analog
settings reported in the
previous read of
GX_
CTRL1[28:4]
.
0x020080
R
3-82
Transceiver PHY Control and Status Registers
UG-01088
2014.12.15
Altera Corporation
Functional Description
