Table 3-19: 40-100GbE MAC and PHY IP Core Without Adapters: Receive Side Signals
Signal Name Direction Description
mac_rx_arst_ST Input
Resets
pcs_rx_arst_ST Input
rx_serial [3:0]
(40GbE and
CAUI–4)
rx_serial [9:0]
(standard
100GbE)
Input Transceiver PHY serial data
interface
lanes_deskewed Output PHY status
clk_rxmac Input Clocks
RX client interface without
adapters (custom streaming
interface)
dout_d[*64-1:0] Output
RX client interface without
adapters (custom streaming
interface)
dout_c[*8-1:0] Output
dout_first_data[-1:0] Output
dout_last_data[*8-1:0] Output
dout_runt_last_data[-
1:0]
Output
dout_payload[-1:0] Output
dout_fcs_error Output
dout_fcs_valid Output
dout_dst_addr_match[-
1:0]
Output
dout_valid Output
pause_match_from_rx Output Pause control and generation
interface
These two signals are not visible
in duplex variations.
pause_time_from_rx[15:0] Output
UG-01088
2014.12.15
Signals of MAC and PHY Variations Without Adapters 3-59
Functional Description Altera Corporation
