Bits Register Description Reset Value Access
[11] Mask for RX buffer posted and completion overflow error. 1b’1 RWS
[10] Reserved 1b’0 RO
[9] Mask for parity error detected on Configuration Space to TX bus
interface.
1b’1 RWS
[8] Mask for parity error detected on the TX to Configuration Space
bus interface.
1b’1 RWS
[7] Mask for parity error detected at TX Transaction Layer error. 1b’1 RWS
[6] Reserved 1b’0 RO
[5] Mask for configuration errors detected in CvP mode. 1b’0 RWS
[4] Mask for data parity errors detected during TX Data Link LCRC
generation.
1b’1 RWS
[3] Mask for data parity errors detected on the RX to Configuration
Space Bus interface.
1b’1 RWS
[2] Mask for data parity error detected at the input to the RX Buffer. 1b’1 RWS
[1] Mask for the retry buffer uncorrectable ECC error. 1b’1 RWS
[0] Mask for the RX buffer uncorrectable ECC error. 1b’1 RWS
Uncorrectable Internal Error Status Register
Table 5-28: Uncorrectable Internal Error Status Register
This register reports the status of the internally checked errors that are uncorrectable. When specific errors are
enabled by the
Uncorrectable Internal Error Mask
register, they are handled as Uncorrectable Internal
Errors as defined in the PCI Express Base Specification 3.0. This register is for debug only. It should only be used to
observe behavior, not to drive custom logic. The access code RW1CS represents Read Write 1 to Clear Sticky.
Bits Register Description
Reset
Value
Access
[31:12] Reserved.
0
RO
[11] When set, indicates an RX buffer overflow condition in a
posted request or Completion
0
RW1CS
