Using the Multi-Gigabit Transceivers

R

Using the Multi-Gigabit Transceivers

The embedded RocketIO™ multi-gigabit transceiver core is based on Mindspeed’s
SkyRail™ technology. Eight transceiver cores are available in each of the FPGAs that can be
used on the XUP Virtex-II Pro Development System.

The transceiver core is designed to operate at any baud rate in the range of 622 Mb/s to
3.125 Gb/s per channel. Only four of the available eight channels are used on the XUP
Virtex-II Pro Development System. Three channels are equipped with low-costs Serial
Advanced Technology Attachment (SATA) connectors and the fourth channel terminates
at user-supplied Sub-Miniature A (SMA) connectors. The SATA channels are split into two
interface formats, two HOST ports (J16, J18), and a TARGET port (J17). The TARGET port
interchanges the transmit and receive differential pairs to allow two XUP Virtex-II Pro
Development Systems to be connected as a simple network, or multiple XUP Virtex-II Pro
Development Systems to be connected in a ring. The SATA specification requires an out-of-
band signalling state that is to be used when the channel is idle. This capability is not
directly provided by the MGTs. Two resistors, an FET transistor, and two AC coupling
capacitors along with special idle state control signals add the out-of-band IDLE state
signaling capability to the MTGs. Additional off-board hardware can be required to
properly interface to generic SATA disk drives.

CF_MPD[3]

I/O

62

AF14

LVCMOS25

8 mA

CF_MPD[4]

I/O

61

AE14

LVCMOS25

8 mA

CF_MPD[5]

I/O

60

AD14

LVCMOS25

8 mA

CF_MPD[6]

I/O

59

AC15

LVCMOS25

8 mA

CF_MPD[7]

I/O

58

AB15

LVCMOS25

8 mA

CF_MPD[8]

I/O

56

AJ9

LVCMOS25

8 mA

CF_MPD[9]

I/O

53

AH9

LVCMOS25

8 mA

CF_MPD[10]

I/O

52

AE10

LVCMOS25

8 mA

CF_MPD[11]

I/O

51

AE9

LVCMOS25

8 mA

CF_MPD[12]

I/O

50

AD12

LVCMOS25

8 mA

CF_MPD[13]

I/O

49

AC12

LVCMOS25

8 mA

CF_MPD[14]

I/O

48

AG10

LVCMOS25

8 mA

CF_MPD[15]

I/O

47

AF10

LVCMOS25

8 mA

CF_MP_CE_Z

O

42

AB16

LVCMOS25

8 mA

CF_MP_OE_Z

O

77

AD17

LVCMOS25

8 mA

CF_MP_WE_Z

O

76

AC16

LVCMOS25

8 mA

CF_MPIRQ

I

41

AD16

LVCMOS25

-

CF_MPBRDY

I

39

AE16

LVCMOS25

-

Table 2-20:

System ACE Connections (Continued)

Signal

Direction

System ACE

Pin

FPGA Pin

I/O Type

Drive
