In addition to the two low-speed expansion connectors, a single 100-pin high-speed
connector is also provided. This connector provides 40 single-ended user I/Os or 34
differential pairs with additional clock resources. These signals are not shared with any
other connector.
provides the pinout information.
The front-mounted Digilent expansion connectors, low speed and high speed, provide the
capability of extending the JTAG-based configuration bitstream to the attached peripheral
cards if required.
For pinout information on the Digilent peripheral boards that are compatible with the XUP
Virtex-II Pro Development System, consult the Digilent Web site at:
Note:
In
, the power rails available on the expansion headers and
connectors are color coded, so they can be easily located in the pinout tables.
Table 2-10:
Top Expansion Header Pinout
J1
Pin
Signal
FPGA
Pin
Digilent
EXP Pin
I/O Type
1
VCC2V5
–
–
–
3
VCC2V5
–
–
–
5
VCC3V3
–
J5.3 J6.3
–
7
VCC3V3
–
J5.3 J6.3
–
9
VCC3V3
–
J5.3 J6.3
–
11
EXP_IO_0
K2
–
LVTTL
13
EXP_IO_1
L2
–
LVTTL
15
EXP_IO_2
N8
–
LVTTL
17
EXP_IO_3
N7
–
LVTTL
19
EXP_IO_4
K4
–
LVTTL
21
EXP_IO_5
K3
–
LVTTL
23
EXP_IO_6
L1
–
LVTTL
25
EXP_IO_7
M1
–
LVTTL
27
EXP_IO_8
N6
J5.4
LVTTL
29
EXP_IO_9
N5
J5.5
LVTTL
31
EXP_IO_10
L5
J5.6
LVTTL
33
EXP_IO_11
L4
J5.7
LVTTL
35
EXP_IO_12
M2
J5.8
LVTTL
37
EXP_IO_13
N2
J5.9
LVTTL
39
EXP_IO_14
P9
J5.10
LVTTL
41
EXP_IO_15
R9
J5.11
LVTTL
43
EXP_IO_16
M4
J5.12
LVTTL
