Chapter 1

XUP Virtex-II Pro Development System

Features

Virtex™-II Pro FPGA with PowerPC™ 405 cores

Up to 2 GB of Double Data Rate (DDR) SDRAM

System ACE™ controller and Type II CompactFlash™ connector for FPGA
configuration and data storage

Embedded Platform Cable USB configuration port

High-speed SelectMAP FPGA configuration from Platform Flash In-System
Programmable Configuration PROM

Support for “Golden” and “User” FPGA configuration bitstreams

On-board 10/100 Ethernet PHY device

Silicon Serial Number for unique board identification

RS-232 DB9 serial port

Two PS-2 serial ports

Four LEDs connected to Virtex-II Pro I/O pins

Four switches connected to Virtex-II Pro I/O pins

Five push buttons connected to Virtex-II Pro I/O pins

Six expansion connectors joined to 80 Virtex-II Pro I/O pins with over-voltage
protection

High-speed expansion connector joined to 40 Virtex-II Pro I/O pins that can be used
differentially or single ended

AC-97 audio CODEC with audio amplifier and speaker/headphone output and line
level output

Microphone and line level audio input

On-board XSGA output, up to 1200 x 1600 at 70 Hz refresh

Three Serial ATA ports, two Host ports and one Target port

Off-board expansion MGT link, with user-supplied clock

100 MHz system clock, 75 MHz SATA clock

Provision for user-supplied clock

On-board power supplies

Power-on reset circuitry

PowerPC 405 reset circuitry
