AERCO Esteem Boiler with EZ-Set Controller User Manual
Page 49
GF-135 Esteem 399 Low NOx Boiler
Chapter 7
OMM-0089_0A
Installation, Operation & Maintenance Manual Gas Piping
Figure 7-2: Gas Valve and Component Locations
(With Gas Valve Shown Separated From the Blower Assembly)
VENTURI
OFFSET PRESSURE
COVER SCREW
GAS VALVE
GAS INLET
ORIFACE
(NATURAL GAS
OR PROPANE)
GASKET
THROTTLE SCREW
(RED PLASTIC SLEEVE)
INLET PRESSURE PORT
BLOWER
ASSEMBLY
Page 49 of 188
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0089_0A
MC1 06/19/14
Ph.: 800-526-0288
