GF-135 Esteem 399 Low NOx Boiler
Appendix A
OMM-0089_0A
Installation, Operation & Maintenance Manual Parts & Dimensions
Figure A-3: Esteem 399 Burner Assembly Components
Item# Part Number Description
1
83025 Combustion Chamber Insulation
2
24230 Burner Head with Gasket
3
58026 Blower with Gasket
4
36059 Burner Plate
5
81194 Burner Plate Gasket (Not Shown)
6
92122 Gas Valve
7
43081 Venturi
8
58094 Igniter and Cable with Gasket
9
58028 Sight Glass Assembly (Glass, Gasket and Bracket)
10
22126 Gas Valve Piping
Page 178 of 188 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0089_0A
MC1 06/19/14 Ph.: 800-526-0288
