Figure 3-96, See figure 3-96 – Dell PowerEdge C8000 User Manual
Page 281

Installing System Components
281
Figure 3-96. Heat Sink Screw Loosening Sequence
6 Gently lift the heat sink off the processor and set the heat sink aside with
thermal grease side facing up. See Figure 3-97.
Figure 3-97. Removing and Installing the Heat Sink
CPU1
CPU2
1
4
5
8
6
7
2
3
1
2
3
4
5
