214 Installing System Components
c Remove the four screws securing the front GPGPU card assembly to
the sled cover. See Figure 3-49.
d Grasp the GPGPU card assembly by its edges, and carefully remove it
from the front GPGPU card riser. See Figure 3-49.
NOTE: An emergency throttling cable is connected underneath the GPGPU card.
Disconnect this cable before lifting the GPGPU card assembly from the sled cover.
See Figure 3-49.
Figure 3-49. Removing and Installing the Front GPGPU Card Assembly
1 M3 screws (4) 2 NVIDIA Tesla M2090 GPGPU card
3 emergency throttling cable 4 front GPGPU card riser
1
4
2
3
