Installing System Components
3 Locate the battery socket on the system board. See "System Board
CAUTION:
To avoid damage to the battery connector, you must firmly support the
connector while installing or removing a battery.
4 Press the "-" side of the battery outward to allow the battery to pop out
from the socket.
5 Lift the battery out of the connector. See Figure 3-122.
Figure 3-122. Removing and Installing the System Battery
Installing the System Battery
WARNING:
There is a danger of a new battery exploding if it is incorrectly
installed. Replace the battery only with the same or equivalent type recommended
by the manufacturer. See your safety information for additional information.
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
1 Hold the new battery with the "+" facing the retention clip on the battery
connector. See Figure 3-122.
2 Insert the "-" side of the battery then push the positive side
1
system battery
2
connector
