Installing System Components
4 Replace the four screws securing the backplane assembly to the hard-drive
cage. See Figure 3-93.
5 Replace the back sled cover. See "Installing the Front and Back Sled
6 Replace the sled. See "Installing a Sled" on page 156.
Cooling Shroud
Removing the Cooling Shroud
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
CAUTION:
Never operate your system with the cooling shroud removed. The
system may get overheated quickly, resulting in shutdown of the system and loss of
data.
1 Remove the sled from the enclosure. See "Removing a Sled" on page 155.
2 Open the sled. See "Removing the Front and Back Sled Covers" on
page 176 or "Removing the Sled Cover" on page 181.
3 Remove the two screws securing the cooling shroud to the sled tray. See
4 Pull on the anchor tab to release the cooling shroud from the heat sink.
5 Lift the cooling shroud up and out of the sled tray. See Figure 3-95.
