Installing System Components

303

Installing the Infiniband Mezzanine Card

CAUTION:

Many repairs may only be done by a certified service technician. You

should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.

1 Align the Infiniband mezzanine card with the screw holes on the bracket.

See Figure 3-110.

2 Replace the three screws securing the Infiniband mezzanine card to the

bracket. See Figure 3-110.

3 Install the mezzanine card bridge board into the mezzanine slot on the

Infiniband mezzanine card. See Figure 3-109.

4 Replace the screw securing the mezzanine card bridge board to the

bracket. See Figure 3-109.

5 Lower the Infiniband mezzanine card assembly to the sled tray.

See Figure 3-108.

6 Replace the two screws securing the Infiniband mezzanine card assembly

to the sled tray. See Figure 3-108.
