Page 269
Installing System Components
269
Installing the Front GPGPU Card Riser
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
1 Place the new GPGPU card riser into the sled cover. See Figure 3-88.
2 Replace the three screws securing the front GPGPU card riser to the sled
cover. See Figure 3-88.
3 Connect the power cable to the front GPGPU card riser. See Figure 3-88.
4 If applicable, connect the emergency throttling cable to the front GPGPU
card riser. See Figure 3-88.
5 Replace the front GPGPU/Xeon Phi card. See "Installing the NVIDIA
Tesla K10 GPGPU Cards" on page 237, "Installing the NVIDIA Tesla K20
GPGPU Cards" on page 251, or "Installing the Xeon Phi 5110P/7120P
6 Close the sled. See "Installing the Sled Cover" on page 184.
7 Replace the sled. See "Installing a Sled" on page 156.
Removing the Back GPGPU Card Riser
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
CAUTION:
Ensure that the back GPGPU card riser is installed on the back of the
sled cover with the proper screw holes. See "Back GPGPU Card Riser Screw
Locations" on page 271" for the location of the screw holes.
1 Remove the sled from the enclosure. See "Removing a Sled" on page 155.
2 Remove the back GPGPU/Xeon Phi card. See "Removing the NVIDIA
Tesla K10 GPGPU Cards" on page 225, "Removing the NVIDIA Tesla K20
GPGPU Cards" on page 239, or "Removing the Xeon Phi 5110P/7120P
