Installing System Components

299

Installing the SAS Mezzanine Card

CAUTION:

Many repairs may only be done by a certified service technician. You

should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.

1 Align the SAS mezzanine card with the screw holes on the bracket.

See Figure 3-105.

2 Replace the three screws securing the SAS mezzanine card to the bracket.

See Figure 3-105.

3 Install the mezzanine card bridge board into the mezzanine slot on the

SAS mezzanine card. See Figure 3-104.

4 Connect all cables to the SAS mezzanine card. See Figure 3-106 or

Figure 3-107 cable routing diagram.

5 Replace the screw securing the mezzanine card bridge board to the

bracket. See Figure 3-104.

6 Lower the SAS mezzanine card assembly to the sled tray. See Figure 3-103.
7 Replace the two screws securing the SAS mezzanine card assembly to the

sled tray. See Figure 3-103.
