Installing System Components
Removing the Node Power Distribution Board Located on the Sled Cover
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
The following replacement procedure applies only to sleds with GPGPU/Xeon
Phi cards.
1 Remove the sled from the enclosure. See "Removing a Sled" on page 155.
2 Remove the sled cover. See "Removing the Sled Cover" on page 181.
3 Remove the GPGPU/Xeon Phi cards. See "Removing the NVIDIA Tesla
K10 GPGPU Cards" on page 225, "Removing the NVIDIA Tesla K20
GPGPU Cards" on page 239, or "Removing the Xeon Phi 5110P/7120P
4 Remove the front GPGPU card riser. See "Removing the Front GPGPU
5 Remove the back GPGPU card riser. See "Removing the Back GPGPU
6 Remove the two screws securing the NPDB assembly to the sled cover.
7 Lift the NPDB assembly from the sled cover. See Figure 3-120.
