154 Installing System Components
Sled Configuration
The following illustrations show a 5-Sled and 4-Sled configuration. A mixture
of differing sled types is also supported in the PowerEdge C8000 server
enclosure. For more information, refer to the PowerEdge C8000 Hardware
Owner’s Manual.
Figure 3-4. PowerEdge C8220X 5-Sled SKU
Figure 3-5. PowerEdge C8220X 4-Sled SKU
The power sleds shown in Figure 3-5 are available on server enclosures that
support internal power source.
