Page 323
Installing System Components
323
3 Connect all cables to the NPDB. See Figure 3-121.
Make sure the emergency throttling cable labeled PS-ON is connected the
NPDB.
4 You must route the cables properly through the tabs on the sled cover to
prevent them from being pinched or crimped.
5 Place the NPDB assembly on the sled cover. See Figure 3-120.
6 Replace the two screws securing the NPDB assembly to the sled cover. See
7 Replace the back GPGPU card riser. See "Installing the Back GPGPU Card
8 Replace the front GPGPU card riser. See "Installing the Front GPGPU
9 Replace the GPGPU/Xeon Phi cards. See "Installing the NVIDIA Tesla K10
GPGPU Cards" on page 237, "Installing the NVIDIA Tesla K20 GPGPU
Cards" on page 251, or "Installing the Xeon Phi 5110P/7120P Cards" on
10 Replace the sled cover. See "Installing the Sled Cover" on page 184.
11 Replace the sled. See "Installing a Sled" on page 156.
System Battery
Removing the System Battery
WARNING:
There is a danger of a new battery exploding if it is incorrectly
installed. Replace the battery only with the same or equivalent type recommended
by the manufacturer. See your safety information for additional information.
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
1 Remove the sled from the enclosure. See "Removing a Sled" on page 155.
2 Open the sled. See "Removing the Front and Back Sled Covers" on
