Installing System Components 325
3 Gently pull the retention clip towards the positive side of the connector
and slide the battery into the connector until the retention clip snaps into
place. See Figure 3-122.
4 Close the sled. See "Installing the Front and Back Sled Covers" on
page 180 or "Installing the Sled Cover" on page 184.
5 Replace the sled. See "Installing a Sled" on page 156.
6 Reconnect the system to the electrical outlet and turn the system on,
including any attached peripherals.
7 Enter the System Setup program to confirm that the battery is operating
properly. See "Using the System Setup Program" on page 59.
8 Enter the correct time and date in the System Setup program's Time and
Date fields.
9 Exit the System Setup program.
System Board
The following table lists the different types of system boards, including model
numbers, supported in the sled.
NOTE: For information about identifying the sled’s system board model number,
see "Identifying System Board Model Number" on page 348.
Removing the System Board
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
1 Remove the sled from the enclosure. See "Removing a Sled" on page 155.
System Board System Board Model Number
V1.0 CN0W6W6G (for sled with Intel Xeon E5-2600 series processor)
V1.1 CN0TND55 (for sled with Intel Xeon E5-2600 series processor)
V1.2 CN09N44V (for sled with Intel Xeon E5-2600V2 series processor)
