Page 240
240
Installing System Components
Figure 3-67. Removing and Installing the Top Cover
5 Remove the front NVIDIA Tesla K20 GPGPU card.
a
Remove the two screws securing the air baffle. See Figure 3-68.
b
Lift the air baffle from the sled cover. See Figure 3-68.
1
top cover
2
M3 screws (5)
3
twin axial cable
2
1
3
