160 Installing System Components
Figure 3-12. Rear 2.5-inch Hard-Drives
Front-Access Hard-Drives
The sled supports up two 2.5-inch hot-plug hard-drives. The following
replacement procedure applies to sled with front-access hard-drives.
Removing a Hard-Drive Blank
CAUTION: To maintain proper system cooling, all empty hard-drive slots must
have hard-drive blanks installed.
1 Turn the lock lever counterclockwise until it points to the unlock symbol.
See Figure 3-13.
2 Slide the release button to open the release handle.
3 Using the release handle, pull the hard-drive blank out of the hard-drive
bay. See Figure 3-13.
2
1
