Great Plains Manufacturing, Inc.
Appendix
81
07/05/2011
401-754Q
Hydraulic Connectors and Torque
Refer to Figure 127 (a hypothetical fitting)
Leave any protective caps in place until immediately prior
to making a connection.
Null4:
Tire Inflation Chart
Null4:
NPT - National Pipe Thread
Note tapered threads, no cone/flare, and no O-ring.
Apply liquid pipe sealant for hydraulic applications
(do not use tape sealant, which can foul filters).
JIC - Joint Industry Conference (SAE J514)
Note straight threads
and the 37
° cone on
“M” fittings (or 37
° flare on “F” fittings). Use no
sealants (tape or liquid) on JIC fittings.
ORB - O-Ring Boss (SAE J514)
Note straight threads
and elastomer O-Ring
.
Prior to installation, to prevent abrasion during
tightening, lubricate O-Ring with clean hydraulic fluid.
Use no sealants (tape or liquid) on JIC fittings.
ORB fittings that need orientation, such as the elbow
depicted, also have a washer
and jam nut
(“adjustable thread port stud”). Back jam nut away
from washer. Thread fitting into receptacle until
O-Ring contacts seat. Unscrew fitting to desired
orientation. Tighten jam nut to torque specification.
2
5
4
9
8
7
5
3
Null4:
Null4:
Null4:
Figure 155
Hydraulic Connector ID
31282
Fittings Torque Values
Fitting
Ft-Lbs
N-m
1
⁄
4
NPT
1.5-3.0 turns past finger tight
9
⁄
16
JIC
18-20
24-27
9
⁄
16
ORB w/jam nut
12-16
16-22
9
⁄
16
ORB straight
18-24
24-32
3
⁄
4
JIC
27-39
37-53
3
⁄
4
ORB w/jam nut
20-30
27-41
3
⁄
4
ORB straight
27-43
37-58
1
1
2
4
5
3
5
7
8
9
Tire Size
Inflation
Tire Warranty Information
8R19.5 LT
760 kPa
All tires are warranted by the original manufacturer of
the tire. Tire warranty information is found online at the
manufacturer’s web sites listed below. For assistance or
information, contact your nearest Authorized Farm Tire
Retailer.
9.5Lx15 305
305 kPa
Manufacturer
Firestone
Gleason
Titan
Web site
