84 Technical Services: 800.283.5936
GROUPS AND CHANNELS
The following tables define the relationship between alpha and numeric representations.
Text commands use the alpha designation, and binary commands use the numeric. In
addition, different groups have different allowable channel ranges.
TYPE AND DEVICE IDS
Type IID Unit ttype Device IID rrange
0xB Converge 590 0x0
0xC Converge 560 0x0
Group Alpha Number
Converge 590
Channel Range
Converge 560
Channel Range
Unknown 0 N/A N/A
Outputs O 2 1 – 3
1 is Record Out
2 is Line Out
3 is Speaker Out
1 – 3
1 is Record Out
2 is Line Out
3 is Speaker Out
Microphones M 3 1 – 9 1 – 6
Line Inputs L 7 1 – 2
1 is Record In
2 is Aux In
1 – 2
1 is Record In
2 is Aux In
Unit
Matrix
Transmit
Local Camera
U 9 0 for Unit Values
1 for Log
0
X 11 TBD TBD
S 13 Phonebook 0
N 15 2 for HTML skin
3 for Firmware
4 for Directory
5 for Firmware Data
1
Receive
T 16 1 1
R 17 1 1
V 19 Sony Mode: 1–7
Canon Mode: 1–9
Sony Mode: 1–7
Canon Mode: 1–9
FIGURE 6.4 Alpha and numeric representations
