Connecting the Converge 21
DIGITAL PHONES
If you have a digital (PBX) telephone service, you need to run an analog extension from
the PBX (recommended for best performance) or use a digital-to-analog telephone line
converter. For more information, contact ClearOne Technical Support.
> Note: If you connect the Converge through a digital-to-analog line converter, you will
not be able to use the tabletop controller or the RAV-Ware dialing interface to make
calls. You will instead need to dial from the digital phone. The phone handset must be
kept off hook for the duration of the call.
To connect to a digital phone
1. Connect one end of the telephone cable into the Line jack on the back of the mixer
and the other end into the digital-to-analog converter.
2. Connect the converter’s power adapter into an electrical outlet.
3. Connect a second telephone cable from the converter to a PBX phone. Consult the
converter’s user manual for more information.
Digital-to-Analog
Converter
AC Adapter
Phone Jack
Digital, PBX,
or Multi-line phone
Converge mixer
Electrical
Outlet
Telco Line Control Camera Lan Mic Pod
Record/Aux
Left In
Right In
Left Out
Right Out
Left +
Left -
Right +
Right -
Power
12V DC 1A
FIGURE 2.20 Connecting the Converge mixer to a digital-to-analog converter
