Appendix

131

SYSRESULT - SYSTEM CHECK RESULT

This command reports the results of the system check. This command is reportable only. It cannot be
queried or set.

A

AR

RG

GU

UM

ME

EN

NTT D

DE

ETTA

AIILLS

S

Name

Type

Size

Values

System Check

Hexadecimal Integer

2

06 – Remote (not implemented)
05 – Network
04 – Telephone
03 – Speaker
02 – Box C
01 – Box B
00 – Box A
All other bits reserved.

Status

Unsigned Integer

2

0 = Fail
1 = Pass

Message

String

40

For the mics: this message will say if a box
is not connected. If a box is connected, the
message will say which microphones fail. If
none fail, the message will say the box
passes. For the speakers: the message will
say if the speakers fail. If they, pass but are
out of phase, the message will say they are
out of phase. Otherwise, the message will
say the speakers pass.
For the telephone on hook: the message
will report the line voltage, the line current,
other results, and if dial tone is
detected.For the telephone off hook: the
message will report the line current, other
results, and if dial tone is detected.The bit
mask for the other results is

For the network check: the box will report if
no IP address is set. If it is set, the box will
ping the gateway. The message will say the
ping failed if it is not returned in 5 s.
Otherwise, the message will report how
many seconds it took to return the ping.

X

X

X

X

X

X

X

X

set if switched from CTR21 to FCC because of low current

set if used DIAL bit while dialing

set if switch from Low Voltage to Japan because of current

set if switch from Low Voltage to FCC because of current

DAA OVL status

DAA DOD status

DAA OPD status
Not used
