MIXER CONSOLE
The Mixer Console allows you to create audio mixes for the different outputs, adjust vol-
ume levels and view the output meters. The audio inputs are shown along the left side of
the window and the audio outputs are along the top.
To open the Mixer Console
1. Click the Mixer C Console icon in the Configuration
screen. The Mixer Console window appears (see
figure 3.11).
To create a mix of audio
1. Select which audio is to be included in each output mix. A check mark indicates the
audio will be included in the output mix.
To adjust audio levels
You can also adjust levels by opening the configuration windows for each component.
Changes made to the levels on the Mixer Console window will be reflected in the
configuration windows.
1. Use the sliders to adjust the audio levels for Playback, Telephone Rx, Line In,
Loudspeaker, Line Output, Telco Tx, Record Out, and the microphones.
FIGURE 3.11 Mixer Console (Converge 560 shown)
