Cabletron Systems 6A000/ZX-250 - Manual (Page 37)

SmartCell 6A000/ZX-250 Reference Manual 2-13
Console Commands
Parameters
Input Parameter Description Value/Field Size Default
[ELANNumber] Number of the ELAN to which the BUS
belongs. 0-127 ALL
[ELANName] Name of the ELAN to which the BUS belongs. Up to 32 characters ELAN000
[ConnectMethod] Type of connection used. PVC, SVC SVC
[ELANType] Data-link type used by the ELAN. 802.3 (Ethernet),
802.5 (TokenRing) 802.3
[Multipoint] Indicates whether control distribute VCC is
PMP (point-to-multipoint) or PTP
(point-to-point). YES: VCC is PMP
NO: VCC is PTP YES
[MTU] Maximum transfer unit assigned for this client. 1516 or 9234 (Ethernet),
4544 (Token Ring) 1516
Output Parameter Description
[ATM Address] ATM address of the ELAN.
[Distribute VPI/VCI] VPI/VCI values of control direct VCC or multicast send VCC.
