2-126 SmartCell 6A000/ZX-250 Reference Manual
Console Commands
NetPrefix
Use NetPrefix to manipulate network ATM address prefixes on a particular port. This 13-byte net prefix is based on a
hierarchical addressing scheme. The default value starts with the first byte being set to 39 (DCC address format),
followed by nine pairs of 00s. The net prefix value is typically supplied by the network side of the UNI (user network
interface). The net prefix, combined with the ESI (End System Identifier) and the SEL (selector) fields supplied by the
user side of UNI, forms the ATM address. See the Structure of ATM address and NetPrefix diagram page 2-121.
Operators
modify, show
Parameters
Descriptions
SERVER SVC
X X
Parameter Description Value/Field Size Default
[PortNumber] Port number on the switch. ALL, A1...A4,
B1...B3, C1...C4,
D1...D4 ALL
[NetPrefix] Net prefix within the ATM address. 13 bytes Current net prefix for that
port
Operator Parameters/Permissions Description
modify
netprefix
[PortNumber] <portnumber>
[NetPrefix] <netprefix>
Administrator
Changes a net prefix for a particular port. Only one net prefix
can be assigned per port. When a net prefix for a port is
modified, all routes under the old net prefix are flushed and
all SVC connections, QSAAL, and ILMI links are released.
You must reboot for this command to take effect.
show
netprefix
[PortNumber] <portnumber>
[NetPrefix] <netprefix>
All
Displays net prefixes for a specified port or for all ports if you
did not specify.
