SmartCell 6A000/ZX-250 Reference Manual 2-191
Console Commands
TrafficDescriptor
Use TrafficDescriptor to manage the templates that describe traffic characteristics of a VC (virtual circuit) that are used
in the creation of PVCs (permanent virtual circuits. A traffic descriptor is a list of parameters that specify the
characteristics of a PVC ATM connection. Each descriptor is defined from a specific combination of parameters.
Operators
add, delete, show
Parameters
SERVER SVC
X X
Input Parameter Description Value/Field Size Default
[Traffic Type] Traffic class type. CBR, NRTVBR,
RTVBR, UBR UBR
[TrafficDescriptorType] Numerical description of traffic class, which
integrates predefined values for three traffic
descriptor variables—end-to-end timing
requirements, traffic type, and broadband bearer
class. See table “Traffic Descriptor Defining Entry
Combinations” for full details. 1-8 8
[TrafficDescriptorIndex] Traffic descriptor index number for deletion. 1-20 1
[PCRCLP01] PCR (peak cell rate) of cells with their CLP (cell
loss priority) bit is equal to one. Specifies the
maximum rate at which cells can be transmitted
over a VC. Kb/s/
0-622000 0
[PCRCLP0] PCR of cells with their CLP bit is equal to zero.
Specifies the maximum rate at which cells can be
transmitted over a VC. Kb/s/
0-622000 0
[SCRCLP01] SCR (sustainable cell rate) of cells with their CLP
bit is equal to one. Specifies maximum average
rate at which cells can be sent over a VC. Kb/s/
0-622000 0
