Cabletron Systems 6A000/ZX-250 - Manual (Page 230)

2-206 SmartCell 6A000/ZX-250 Reference Manual
Console Commands
WellKnownAddress
Use WellKnownAddress to manage the mapping between the ATM forum defined well-known address for the LECS
(LAN emulation configuration server) and a registered address for another LECS.
Operators
add, delete, show, flush
Parameters
SERVER SVC
X X
Input Parameter Description Value/Field Size Default
[WellKnownAddress] ATM address used by a client to
connect to a server. The first byte
(AFI byte) must be hex 47. The
well-known address is an alias for
the registered address of the server. 13-20 byte hex-based/
Up to 59 characters 47:00:79:00:00:00:00:00
:00:00:00:00:00:00:A0:3
E:00:00:01:00
[RegisteredAddress] ATM address of the server registered
in the network. 13-20 byte hex-based/
Up to 59 characters Server ATM Address
[WellKnownAddrId] Unique entry ID generated by the
switch for each well-known address
mapping. 1, 2, 3, 4.../
n/a 1
[RouteType] Route type can be either static or
dynamic. ALL, STATIC,
DYNAMIC ALL
Output Parameter Description
[AddressId] Same as [WellKnownAddrId] Input Parameter.
[AddressType] Indicates how address is configured in the system. Static addresses are manually entered.
Dynamic addresses are registered by ILMI procedures.
