APPENDIX G
49’1340 e FlexPak 3000 G-7
Table G.1 - User Quick Reference Table for Input Parameters (continued)
Par. Parameter Parameter Selection / Pg Initial Factory User Data
No. Adjustment Range B- Setting Date Setting
Level Detectors
602 LEVEL DETECT 1 SELECT
• SPD SOURCE SELECT OUT
• SPEED RAMP INPUT TP
• SPEED RAMP OUTPUT
• SPD LOOP FEEDBACK
• CML FEEDBACK
24 SPD LOOP
FEEDBACK
603 LEVEL DETECT 1 THRESH
• 0.1 to 100.0% if LEVEL
DETECT 1 SELECT is not set
to CML FEEDBACK
• 0.1 to MAXIMUM CURRENT%
if LEVEL DETECT 1 SELECT
is set to CML FEEDBACK
24 10.0%
604 LEVEL DETECT 1 DELAY 0.0 - 300.0 sec 24 10.0 sec
605 LEVEL DETECT 2 SELECT
• SPD SOURCE SELECT OUT
• SPEED RAMP INPUT TP
• SPEED RAMP OUTPUT
• SPD LOOP FEEDBACK
• CML FEEDBACK
25 SPEED RAMP
INPUT TP
606 LEVEL DETECT 2 THRESH
• 0.1 - 100.0% if LEVEL
DETECT 2 SELECT is not set
to CML FEEDBACK
• 0.1 to MAXIMUM CURRENT%
if LEVEL DETECT 2 SELECT
is set to CML FEEDBACK
25 10.0%
607 LEVEL DETECT 2 DELAY 0.0 - 300.0 sec 24 10.0 sec
608 TACH LOSS SCR ANGLE 0 to 127 (degrees) 50 109
609 PHASE LOSS DETECT EN DISABLE, ENABLE 42 ENABLE
Outer Current Loop
800 OCL REFERENCE SELECT • REGISTER
• ANALOG IN 1
• ANALOG IN 2
• FREQUENCY IN
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
40 REGISTER
801 OCL REF REGISTER -4095 - 4095 40 0
802 OCL REF RAMP TIME 0.0 - 300.0 sec 39 10.0 sec
803 OCL REF ROUNDING 0 - 50% 40 0%
804 OCL FEEDBACK SELECT • NONE
• CML FEEDBACK
• ANALOG IN 1
• ANALOG IN 2
• 5=SPEED LOOP OUTPUT
• 6=ANALOG AUTO REF
• 7= NETW IN REG 1 (4.1 only)
• 8= NETW IN REG 2 (4.1 only)
• 9= NETW IN REG 3 (4.1 only)
37 CML
FEEDBACK
805 OCL LEADLAG SELECT • LEAD/LAG
• BYPASS
• LAG/LEAD
38 BYPASS
806 OCL LEADLAG LOW FREQ 0.01 - 34.90 rad/s 37 1.00 rad/s
807 OCL LEADLAG RATIO 2 - 20 37 10
