NETW OUT REG 3 SELECT (P.904)
Selects which parameter is to be monitored in drop_1, register 9. Select the parameter to monitor by
programming the parameter number. For example, setting this parameter equal to 588 will write the
value of output parameter FIELD DELTA to register 9.
Parameter Range:
-32768 to 32767
Default Setting:
0
Parameter Type:
Tuneable
OIM Menu Path(s):
Network Communications
NETW REGISTER MAP SEL (P.914)
Only available if an AutoMax Network Communication Option board is installed.
Indicates which register map configuration will be used for the AutoMax Network Communic. board.
Parameter Range:
1 = ORIGINAL,
2 = ALTERNATE
Default Setting:
1
Parameter Type:
Configurable
OIM Menu Path(s):
Additional Parameters
The alternate map exchanges several registers between the Drop_1 area and other drops in addition to
a few new registers. The values displayed when using the AutoMax network are shown in brackets.
NOMINAL AC LINE FREQ (P.306)
The nominal A-C line frequency (typically 50 or 60 Hz).
Parameter Range:
48 to 62 Hz
Default Setting:
50
Parameter Type:
Configurable
OIM Menu Path(s):
Current Minor Loop (CML) - Three Phase AC Line
NOMINAL AC LINE VOLTS (P.307)
The nominal A-C line RMS voltage.
Parameter Range:
200 to 575 VAC on types with nominal voltage up to 500 VAC
300 to 850 VAC on types with nominal voltage 690 VAC (see 4.5.11)
Default Setting:
400 VAC
Parameter Type:
Configurable
OIM Menu Path(s):
Current Minor Loop (CML) - Three Phase AC Line
Refer also to Parameter:
MOTOR RATED ARM VOLTS (P.009)
NORMALIZED INERTIA (P.222)
The time required to accelerate the motor and load inertia from zero to motor base speed at MOTOR
RATED ARM AMPS and MOTOR HOT FLD AMPS.
This parameter is set by the speed loop self-tuning procedure or is entered by the operator directly.
Parameter Range:
0.05 to 65.20 seconds
Default Setting:
1.00 second
Parameter Type:
Tuneable
OIM Menu Path(s):
Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Tuning
Refer also to Parameters:
INERTIA COMP SELECT (P.221),
MOTOR HOT FLD AMPS (P.510),
MOTOR RATED ARM AMPS (P.008)
