APPENDIX G
49’1340 e
FlexPak 3000
G-5
Table G.1 - User Quick Reference Table for Input Parameters (continued)
Par.
Parameter
Parameter Selection /
Pg Initial Factory
User Data
No.
Adjustment Range
B-
Setting
Date
Setting
Digital Outputs Set-up (on I/O card)
409
DIG OUT 1 SELECT
•
LEVEL DETECT 1 OUTPUT
•
LEVEL DETECT 2 OUTPUT
•
IN CURRENT LIMIT
•
DRIVE READY
•
NETW COMM STATUS
•
NETW IN REG 1
•
NETW IN REG 2
•
NETW IN REG 3
13
LEVEL
DETECT 1
OUTPUT
410
DIG OUT 1 CONTACT TYP
•
NORMAL OPEN
•
NORMAL CLOSED
13
NORMAL
OPEN
411
DIG OUT 2 SELECT
•
LEVEL DETECT 1 OUTPUT
•
LEVEL DETECT 2 OUTPUT
•
IN CURRENT LIMIT
•
DRIVE READY
•
NETW COMM STATUS
•
NETW IN REG 1
•
NETW IN REG 2
•
NETW IN REG 3
14
LEVEL
DETECT 2
OUTPUT
412
DIG OUT 2 CONTACT TYP
•
NORMAL OPEN
•
NORMAL CLOSED
13
NORMAL
OPEN
Analog Inputs / Outputs (on I/O card)
413
ANLG IN 1 SIG TYPE
•
0-10V,
±10V
•
4-20 mA,
10-50 mA
3
±10 V
414
ANLG IN 1 ZERO ADJ
-200 - 200
3
0
415
ANLG IN 1 GAIN ADJ
0.750 - 2.250
3
1.000
416
ANLG IN 2 ZERO ADJ
-200 - 200
4
0
417
ANLG IN 2 GAIN ADJ
0.750 - 2.250
4
1.000
418
ANLG OUT 1 SELECT
•
CML FEEDBACK
•
CML REFERENCE
•
CML ERROR
•
SPD LOOP FEEDBACK
•
SPD LOOP REFERENCE
•
SPD LOOP ERROR
•
SPD LOOP OUTPUT
•
SPEED RAMP OUTPUT
•
SPEED RAMP INPUT TP
•
SPD SOURCE SELECT OUT
•
TRIM OUTPUT
•
ARMATURE VOLTAGE
•
ANALOG TACH FEEDBACK
•
PULSE TACH FEEDBACK
•
ZERO
•
FULL SCALE
•
POWER OUTPUT
•
OCL REFERENCE
•
OCL RAMP OUTPUT
•
OCL FEEDBACK
•
OCL OUTPUT
•
FIELD REFERENCE
•
FIELD FEEDBACK
•
NETW IN REG 1
•
NETW IN REG 2
•
NETW IN REG 3
5
ZERO
