FlexPak 3000 Main Menu
Quick Start
MOTOR BASE SPEED/TOP SPEED (P.011)
MOTOR RATED ARM AMPS (P.008)
MOTOR RATED ARM VOLTS (P.009)
REVERSE DISABLE (P.015)
FEEDBACK SELECT (P.200)
ANLG TACH VOLTS/1000 (P.203)
ACCELERATION TIME (P.001)
DECELERATION TIME (P.002)
MINIMUM SPEED (P.003)
MAXIMUM SPEED (P.004)
JOG ACCEL/DECEL TIME (P.013)
JOG SPEED 1 (P.012)
POSITIVE CURRENT LIM (P.005)
NEGATIVE CURRENT LIM (P.006)
IR COMPENSATION (P.206)
J11 ANLG TACH VLT SCL (P.792)
J14 ANLG TACH VLT RNG LOW (P.793)
J18 ARM I FB RESISTOR (P.395)
Self Tune
Drive Reference
Drive Reference Test Points
ANALOG AUTO REFERENCE (P.188)
ANALOG MAN REFERENCE (P.192)
ANALOG MAN TRIM REF (P.194)
SPD SOURCE SELECT OUT (P.193)
DRAW PERCENTAGE OUT (P.196)
TRIM OUTPUT (P.197)
SPEED RAMP INPUT TP (P.198)
SPEED RAMP OUTPUT (P.199)
JOG RAMP OUTPUT (P.294)
SPD LOOP REFERENCE (P.295)
MOP OUTPUT (P.191)
Drive Reference Trim
TRIM REF REGISTER (P.107)
TRIM REFERENCE SELECT (P.108)
TRIM RANGE (P.109)
TRIM MODE SELECT (P.110)
Drive Reference Limits
TOP SPEED (P.011)
MAXIMUM SPEED (P.004)
MINIMUM SPEED (P.003)
REVERSE DISABLE (P.015)
AUTO MODE MIN BYPASS (P.111)
Drive Reference Ramp
ACCELERATION TIME (P.001)
DECELERATION TIME (P.002)
S-CURVE ROUNDING (P.014)
JOG ACCEL/DECEL TIME (P.013)
AUTO MODE RAMP BYPASS (P.112)
MOP ACCEL TIME (P.115)
MOP DECEL TIME (P.120)
