APPENDIX B
49’1340 e FlexPak 3000 B-1
FlexPak 3000 User Input Parameters
This appendix provides an alphabetized list of input parameters with their associated default values,
description and the OIM Menu path(s) for access. Partial control block diagrams are provided for some
parameters. Refer to Appendix D for full block diagrams.
ACCELERATION TIME (P.001)
Amount of time it will take the drive to reach TOP SPEED from 0 speed. Smaller changes in speed will
take proportionately less time. In proportional trim mode, this time value is modified by DRAW
PERCENTAGE OUT.
Parameter Range: 0.1 to 300.0 seconds (actual minimum setting based on connected inertia)
Default Setting: 5 seconds
Parameter Type: Tuneable
OIM Menu Path(s): Drive Reference - Drive Reference Ramp Quick Start
Refer also to parameters: TRIM MODE SELECT (P.110)
AMX NETW REF SELECT (P.911)
AutoMax Network Reference Selection. Selects whether the drive reference value is obtained from the
designated register within the drop register image or from one of the eight network broadcast registers
when CONTROL SOURCE SELECT is set to NETWORK.
Parameter Range: DIRECT
BROADCAST n
where n = 1 to 8 (0, or 1 to 8, respectively)
Default Setting: DIRECT
Parameter Type: Configurable
OIM Menu Path(s): Network Communications
ANALOG TACH GAIN ADJ (P.201)
Used to scale the analog tachometer feedback signal after it has been conditioned by the drive
hardware. Typically, it will be 1.000.
Parameter Range: 0.750 to 1.250
Default Setting: 1.000
Parameter Type: Tuneable
OIM Menu Path(s): Speed/Voltage Loop (SPD)-Speed /Voltage Loop (SPD) Feedback
WARNING
The incorrect setting of this parameter can cause an overspeed condition. This parameter must be set
by a qualified person who understands the significance of setting it. Set the value of this parameter
accurately per your application requirements. Failure to observe this precaution could result in bodily
injury.
