Parameter-to-Register Cross Reference

B-7

Sync Direction (H.016)

3, V/Hz

16

3, V/Hz

48

Terminal Strip Analog Input Config (P.011)

2

7

1

44

Terminal Strip Analog Input Gain (P.010)

2

6

1

43

Terminal Strip Analog Input Offset (P.009)

2

5

1

42

Terminal strip analog input value

1

4

n/a

Terminal Strip Analog Output Source (P.012)

2

8

2

34

0 to 7

Terminal strip digital input 1 (start)

1

0

8

n/a

Terminal strip digital input 2 (stop)

1

0

9

n/a

Terminal strip digital input 3 (fault reset)

1

0

10

n/a

Terminal strip digital input 4 (run/jog)

1

0

11

n/a

Terminal strip digital input 5 (function loss)

1

0

12

n/a

Terminal strip digital inputs 6

1

0

13

n/a

Terminal strip digital inputs 7

1

0

14

n/a

Terminal strip digital inputs 8

1

0

15

n/a

Torque Boost Voltage (H.003)

3, V/Hz

3

3, V/Hz

35

Torque or speed regulation

1

26

0

n/a

Torque Reference Source (U.000)

3, Vector

0

0 to 7

1

58

0 to 7

Torque Regulator Integral Gain (U.015)

3, Vector

11

3, Vector

40

Torque Regulator Prop Gain (U.014)

3, Vector

10

3, Vector

39

Torque Self-Tune Result (U.009)

3, Vector

8

n/a

Trim Gain Percentage (P.015)

1

22

1

45

Trim Reference Source (P.014)

2

10

1

57

Tunable Booleans (Read)

2

24

n/a

Tune/config input enable

1

0

6

1

32

14

Tune/config update synchronization flag

1

0

7

1

32

15

U.000, Torque Reference Source

3, Vector

0

0 to 7

1

58

0 to 7

U.001, Encoder PPR

3, Vector

1

3, Vector

32

U.002, Motor Poles

3, Vector

2

3, Vector

33

U.003, Motor Nameplate Base Freq

3, Vector

3

3, Vector

34

U.004, Motor Nameplate Amps

3, Vector

4

3, Vector

35

U.005, Motor Nameplate RPM

3, Vector

5

3, Vector

36

U.006, Magnetizing Current

3, Vector

6

3, Vector

37

U.007, Motor Nameplate Volts

3, Vector

7

3, Vector

38

U.008, Torque Self-Tune Enable

n/a

n/a

U.009, Torque Self-Tune Result

3, Vector

8

n/a

U.012, Speed Regulator Prop Gain

1

24

1

47

U.013, Speed Regulator Integral Gain

1

25

1

48

U.014, Torque Regulator Prop Gain

3, Vector

10

3, Vector

39

U.015, Torque Regulator Integral Gain

3, Vector

11

3, Vector

40

U.016, Field Weakening Start RPM

3, Vector

12

3, Vector

41

U.017, Motor Top Speed

3, Vector

13

3, Vector

42

U.018, AC Line Volts

3, Vector

14

3, Vector

43

U.019, Flux Current Regulator Prop Gain

3, Vector

15

3, Vector

44

U.020, Flux Current Reg Integral Gain

3, Vector

16

3, Vector

45

U.021, Rotor Time Constant

3, Vector

17

3, Vector

46

U.022, Motor Nameplate Horsepower

3, Vector

18

3, Vector

47

U.023, Low DC Bus Fault Avoid Enable

2

19

2

2

40

2

U.024, High DC Bus Fault Avoid Enable

2

19

3

2

40

3

U.025, Zero Speed Hold Time

3, Vector

19

3, Vector

48

U.026, Current Compounding Gain

2

25

3, Vector

49

U.027, Inertia Compensation Gain

2

29

3, Vector

50

Description or GV3000/SE Parameter

Read Only

Read/Write

Drop

Register

Bit

Drop

Register

Bit
