2-32

AutoMax Network Communication Option Board for the GV3000/SE AC Drive

2.9

Installing the AutoMax Network Option Board in
2 to 15 Amp and 24 to 30 Amp GV3000/SE Bookshelf
Drives

Use the procedure in this section to install the AutoMax Network option board in the
drives listed in table 2.6.

This procedure requires access to the right side of the drive. Remove the drive from
the panel if necessary.

!

ATTENTION: Only qualified electrical personnel familiar with the
construction and operation of this equipment and the hazards involved
should install, adjust, operate, or service this equipment. Read and
understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in
severe bodily injury or loss of life.

ATTENTION: The drive is at line voltage when connected to incoming
AC power. Disconnect, lock out, and tag all incoming power to the drive
before performing the following procedure. Failure to observe this
precaution could result in severe bodily injury or loss of life.

ATTENTION: DC bus capacitors retain hazardous voltages after input
power has been disconnected. After disconnecting input power, wait five
minutes for the DC bus capacitors to discharge and then check the
voltage with a voltmeter to ensure the DC bus capacitors are discharged
before touching any internal components. Failure to observe this
precaution could result in severe bodily injury or loss of life.

ATTENTION: The drive contains printed circuit boards that are
static-sensitive. An anti-static wrist band should be worn by any person
who touches the drive’s components, connectors, or wiring. Erratic
machine operation and damage to, or destruction of, equipment can
result if this procedure is not followed.

Table 2.6 – Model Numbers for 2 to 15 Amp and 24 to 30 Amp Drives

2 to 15 Amp

24 to 30 Amp

31ER40xx

31ET40xx

240ER40xx

240ET40xx

38ER40xx

38ET40xx

300ER40xx

300ET40xx

55ER40xx

55ET40xx

85ER40xx

85ET40xx

126ER40xx

126ET40xx

150ER40xx

150ET40xx
