Rockwell Automation GV3000/SE AC Drive AutoMax Network Communication Board, M/N 2AX3000 - Manual (Page 30)

Installation 2-21
2.6 Installing the AutoMax Network Option Board in
15 to 25 HP and 25 to 60HP @ 460V Drives
Use this procedure to install the AutoMax Network option board in drives with the
model numbers listed in table 2.5.
Unless otherwise indicated, keep all hardware that is removed. You will need it for
reassembly. This includes screws, lock washers, and rivets.
If the drive is panel-mounted, this procedure will be easier to perform if the drive is
removed from the panel.
!
ATTENTION: Only qualified electrical personnel familiar with the
construction and operation of this equipment and the hazards involved
should install, adjust, operate, or service this equipment. Read and
understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in
severe bodily injury or loss of life.
ATTENTION: The drive is at line voltage when connected to incoming
AC power. Disconnect, lock out, and tag all incoming power to the drive
before performing the following procedure. Failure to observe this
precaution could result in severe bodily injury or loss of life.
ATTENTION: DC bus capacitors retain hazardous voltages after input
power has been disconnected. After disconnecting input power, wait five
minutes for the DC bus capacitors to discharge and then check the
voltage with a voltmeter to ensure the DC bus capacitors are discharged
before touching any internal components. Failure to observe this
precaution could result in severe bodily injury or loss of life.
ATTENTION: The drive contains printed circuit boards that are
static-sensitive. An anti-static wrist band should be worn by any person
who touches the drive’s components, connectors, or wiring. Erratic
machine operation and damage to, or destruction of, equipment can
result if this procedure is not followed.
Table 2.5 – Model Numbers for 15 to 25 HP and 25 to 60 HP@460V Drives
15 to 25 HP 25 to 60 HP
15V41xx
15V42xx 25V41xx
25V42xx
20V41xx
20V42xx 30V41xx
30V42xx
25G41xx
25G42xx 40V41xx
40V42xx
50V41xx
50V42xx
60G41xx
60G42xx
