B-4
AutoMax Network Communication Option Board for the GV3000/SE AC Drive
Network speed PI limit control enable
n/a
1
53
2
nld (Identification request not performed)
1
13
3
n/a
Number of error log entries
1
14
0 to 7
n/a
NVRAM
write failure (EEr)
1
13
5
n/a
OC (overcurrent, steady state)
1
12
0
n/a
OCA (overcurrent, at acceleration)
1
12
1
n/a
OCb (overcurrent, at DC braking)
1
12
3
n/a
OCd (overcurrent, at deceleration)
1
12
2
n/a
OF (overfrequency)
1
12
15
n/a
OH (drive overtemperature)
1
12
7
n/a
OL (electronic thermal overload)
1
12
6
n/a
OPL (motor output phase loss)
1
12
14
n/a
Option port speed PI high limit
n/a
1
59
Option port speed PI low limit
n/a
1
60
Option port speed/torque direct ref
n/a
1
33
Option port trim ref (when P.014=2)
n/a
1
34
Option Port: Com Loss Response (P.062)
1
29
1
62
Option Port: Network Ref Source (P.063)
1
30
0 to 7
1
63
0 to 7
Option Port: Netw Trim Ref Source (P.064)
1
30
8 to 15
1
63
8 to 15
Option Port: Type and Version (P.065)
2
31
n/a
OSP (overspeed; vector only)
1
12
13
n/a
Outer control loop (OCL) enable
n/a
1
32
5
Outer control loop enabled
1
26
2
n/a
OCL Feedback (U.040)
3, Vector
0
8 to 15
1
58
8 to 15
OCL Integral Gain (U.046)
3, Vector
27
3, Vector
61
OCL direct reference
n/a
1
34
OCL Lead/Lag Low Freq. (U.042)
3, Vector
23
3, Vector
57
OCL Lead/Lag Ratio (U.043)
3, Vector
24
3, Vector
58
OCL Lead/Lag Select (U.041)
3, Vector
21
8 to 15
3, Vector
54
8 to 15
OCL Proportional Gain (U.045)
3, Vector
26
3, Vector
60
OCL Proportional Trim Enable (U.048)
2
19
4
2
40
4
OCL Reference Gain (U.044)
3, Vector
25
3, Vector
59
OCL Trim Range Percentage (U.047)
3, Vector
30
3, Vector
62
Output Current
1
7
n/a
Output Phase Loss Enable (P.045)
2
24
1
2
38
1
Output Relay Configuration (P.013)
2
9
1
56
Output speed/frequency (
RPM
display)
1
5
n/a
Output voltage (
VOLTS
display)
1
6
n/a
Overcurrent, at acceleration (OCA)
1
12
1
n/a
Overcurrent, at DC braking (OCb)
1
12
3
n/a
Overcurrent, at deceleration (OCd)
1
12
2
n/a
Overcurrent, steady state (OC)
1
12
0
n/a
Overfrequency (OF)
1
12
15
n/a
Overfrequency Limit (H.022)
3, V/Hz
22
3, V/Hz
54
Overspeed; vector only (OSP)
1
12
13
n/a
P.000, Control Source
1
16
n/a
P.001, Accel Time 1 (RAMP 1)
1
17
1
37
P.002, Decel Time (RAMP 1)
1
18
1
38
P.003, Minimum Speed
1
19
1
39
P.004, Maximum Speed
1
20
1
40
P.005, Current Limit
1
21
1
41
Description or GV3000/SE Parameter
Read Only
Read/Write
Drop
Register
Bit
Drop
Register
Bit
