Parameter-to-Register Cross Reference
B-3
H.021, AC Line Volts
3, V/Hz
21
3, V/Hz
53
H.022, Overfrequency Limit
3, V/Hz
22
3, V/Hz
54
HId (high time identification aborted)
1
13
2
n/a
High DC Bus Fault Avoid. Enable (U.024)
2
19
3
2
40
3
High DC bus voltage (HU)
1
12
4
n/a
High line voltage (HIL)
1
13
4
n/a
High time identification aborted (HID)
1
13
2
n/a
Identification request not performed (nld)
1
13
3
n/a
Identification Result (H.019)
3, V/Hz
19
n/a
Inertia Compensation Gain (U.027)
2
29
3, Vector
50
Input phase loss (IPL)
1
13
11
n/a
Input Power/Snubber Config. (H.017)
3, V/Hz
17
3, V/Hz
49
IPL (input phase loss)
1
13
11
n/a
Jog Ramp Accel Time (P.021)
2
13
2
35
Jog Ramp Decel Time (P.022)
2
14
2
36
Jog Speed Reference (P.020)
2
12
1
49
Level Sense Start Enable (P.054)
2
19
1
2
40
1
Line Dip Ride-Through Time (P.042)
2
21
2
42
Losses Compensation Gain (U.028)
2
30
3, Vector
51
Low DC Bus Fault Avoid. Enable (U.023)
2
19
2
2
40
2
Low DC bus voltage (LU)
1
12
5
n/a
Magnetizing Current (U.006)
3, Vector
6
3, Vector
37
Manual Reference Preset Enable (P.053)
2
24
2
2
38
2
Maximum Speed (P.004)
1
20
1
40
Minimum Speed (P.003)
1
19
1
39
Missing Power Module ID connector (PUc)
1
13
9
n/a
Motor Nameplate Amps (H.002)
3, V/Hz
2
3, V/Hz
34
Motor Nameplate Amps (U.004)
3, Vector
4
3, Vector
35
Motor Nameplate Base Frequency (H.001)
3, V/Hz
1
3, V/Hz
33
Motor Nameplate Base Frequency (U.003)
3, Vector
3
3, Vector
34
Motor Nameplate Horsepower (U.022)
3, Vector
18
3, Vector
47
Motor Nameplate RPM (U.005)
3, Vector
5
3, Vector
36
Motor Nameplate Volts (H.000)
3, V/Hz
0
3, V/Hz
32
Motor Nameplate Volts (U.007)
3, Vector
7
3, Vector
38
Motor output phase loss (OPL)
1
12
14
n/a
Motor Overload Enable (P.040)
2
19
0
2
40
0
Motor Overload Type (P.041)
2
20
2
41
Motor Poles (U.002)
3, Vector
2
3, Vector
33
Motor Top Speed (U.017)
3, Vector
13
3, Vector
42
Network communication loss (nCL)
1
13
0
n/a
Network Connection Type (P.061)
1
28
1
61
Network inertia comp register enable
n/a
1
53
1
Network inertia compensation
n/a
1
35
Network output register 1
1
8
n/a
Network output register 2
1
9
n/a
Network output register 3
1
10
n/a
Network output register 4
1
11
n/a
Network Output Register 1 Source (P.066)
2
3
0 to 7
2
45
0 to 7
Network Output Register 2 Source (P.067)
2
3
8 to 15
2
45
8 to 15
Network Output Register 3 Source (P.068)
2
4
0 to 7
2
46
0 to 7
Network Output Register 4 Source (P.069)
2
4
8 to 15
2
46
8 to 15
Description or GV3000/SE Parameter
Read Only
Read/Write
Drop
Register
Bit
Drop
Register
Bit
