Parameter-to-Register Cross Reference
B-5
P.006, Second Menu Password
n/a
n/a
P.007, Term Strip Digital Inputs Configure
n/a
n/a
P.008, Term Strip Speed Reference Source
n/a
n/a
P.009, Terminal Strip Analog Input Offset
2
5
1
42
P.010, Terminal Strip Analog Input Gain
2
6
1
43
P.011, Term Strip Analog Input Configure
2
7
1
44
P.012, Term Strip Analog Output Source
2
8
2
34
0 to 7
P.013, Output Relay Configuration
2
9
1
56
P.014, Trim Reference Source
2
10
1
57
P.015, Trim Gain Percentage
1
22
1
45
P.016, Draw Gain Percentage
1
23
1
46
P.017, Accel Time 2 (RAMP 2)
n/a
n/a
P.018, Decel Time 2 (RAMP 2)
n/a
n/a
P.019, S-Curve Enable
2
11
2
39
P.020, Jog Speed Reference
2
12
1
49
P.021, Jog Ramp Accel Time
2
13
2
35
P.022, Jog Ramp Decel Time
2
14
2
36
P.023, MOP Accel/Decel Time
n/a
n/a
P.024, MOP Reset Configuration
n/a
n/a
P.025, Stop Type
2
15
0 to 7
1
50
P.026, Function Loss Response
2
16
1
51
P.027, Forward/Reverse Configuration
2
17
2
37
P.028, Speed Display Scaling
2
18
1
52
P.029, Elapsed Time Meter
1
27
n/a
P.030, Elapsed Time Meter Reset
n/a
1
53
0
P.031, Preset Speed 1
n/a
n/a
P.032, Preset Speed 2
n/a
n/a
P.033, Preset Speed 3
n/a
n/a
P.034, Preset Speed 4
n/a
n/a
P.035, Preset Speed 5
n/a
n/a
P.036, Preset Speed 6
n/a
n/a
P.037, Preset Speed 7
n/a
n/a
P.038, Preset Speed 8
n/a
n/a
P.039, Encoder Loss Enable
2
24
0
2
38
0
P.040, Motor Overload Enable
2
19
0
2
40
0
P.041, Motor Overload Type
2
20
2
41
P.042, Line Dip Ride-Through Time
2
21
2
42
P.043, Fault Auto Reset Attempts
2
22
2
43
P.044, Fault Auto Reset Time
2
23
2
44
P.045, Output Phase Loss Enable
2
24
1
2
38
1
P.047, Carrier Frequency (kHz)
2
26
2
47
P.048, Volts/Hertz or Vector Regulation
2
27
n/a
P.049, Country Defaults
2
28
2
49
P.050, Restore Defaults
n/a
n/a
P.051, Programming Disable
n/a
n/a
P.052,
AUTO
/
MAN
Key Disable
2
24
3
2
38
3
P.053, Manual Reference Preset Enable
2
24
2
2
38
2
P.054, Level Sense Start Enable
2
19
1
2
40
1
P.055,
STOP
/
RESET
Key Disable
2
24
4
2
38
4
P.060, Network Drop Number
n/a
n/a
P.061, Network Connection Type
1
28
1
61
Description or GV3000/SE Parameter
Read Only
Read/Write
Drop
Register
Bit
Drop
Register
Bit
